Hot Melt Adhesive Film
Hot melt adhesive film is a versatile and high-performance bonding material available in materials such as PO, PES, PA, EVA, and TPU. Its strong adhesion, excellent durability, and heat-sealing properties make it an ideal choice for textiles, nonwoven fabrics, leather, and other garment components. Widely used in applications ranging from clothing to industrial uses, this film offers precise and efficient solutions for diverse bonding needs.
product introduce
Hot Melt Adhesive Film Product Highlights:
1.Available in multiple materials (PO, PES, PA, EVA, TPU) to suit different bonding requirements and applications.
2.Strong adhesion properties ensure durable bonding for textiles, leather, nonwoven fabrics, and more.
3.Highly resistant to heat and water, providing long-lasting performance in demanding environments.
4.Eco-friendly and customizable, catering to a wide range of garment and industrial uses.
additional information
| Minimum Order Quantity | 500kg per type |
|---|---|
| Certification | OEKO-TEX, GRS, SGS |
| Price Range | USD $1.5 – $2.5/kg (Depending on material and weight) |
| Packaging | Roll packed in PE plastic bags, with an outer strong woven polybag. |
| Transportation | Via sea, air, or express logistics. |
| Payment Terms | L/C, D/P, T/T, Western Union, PayPal |
| Delivery Time | 7-15 days based on order size |
| Monthly Production Capacity | 2,000,0000 meters |
| Roll Length | 100m-1000m/roll |
| Special Customization | Available for color, weight, and width upon request. |
Hot Melt Adhesive Film Product Specifications
| Material | Series | Thickness (mm) | Width (cm) | Melting Point (°C) | Heating Press Temp. (°C) | Pressing Time (s) | Pressure (kgf/cm²) | Water Resistance | Dry Cleaning Resistance | Bonding Strength (N/2.5cm) |
| PA | FFA-L | 0.02-0.20 | 0.5-160 | 105-110 | 115-125 | 15-20 | 0.3-0.5 | Good | Excellent | >20 |
| PA | FFA-H | 0.02-0.20 | 0.5-160 | 125-135 | 105-110 | 15-20 | 0.3-0.5 | Excellent | Excellent | >20 |
| PA | FFS-L | 0.02-0.20 | 0.5-160 | 65 | 80-100 | 15-20 | 0.3-0.5 | Good | X | >10 |
| PA | FFS | 0.02-0.20 | 0.5-160 | 85 | 110-130 | 15-20 | 0.3-0.5 | Good | X | >10 |
| PES | FFS-M | 0.02-0.20 | 0.5-160 | 115-120 | 120-130 | 15-20 | 0.3-0.5 | Good | X | >10 |
| PES | FWS-MH | 0.02-0.20 | 0.5-160 | 120-130 | 130-140 | 15-20 | 0.3-0.5 | Good | X | >10 |
| PES | FWS-H | 0.02-0.20 | 0.5-160 | 150-160 | 160-170 | 15-20 | 0.3-0.5 | Good | X | >10 |
| PO | FFO | 0.02-0.20 | 0.5-160 | 80-90 | 130-150 | 15-20 | 0.3-0.5 | Excellent | X | >10 |
| TPU | FFU | 0.02-0.20 | 0.5-160 | 65 | 85-110 | 15-20 | 0.3-0.5 | Good | Excellent | >15 |
| TPU | FFU-M | 0.02-0.20 | 0.5-160 | 110 | 135-145 | 15-20 | 0.3-0.5 | Good | Excellent | >15 |
| EVA | FFE-L | 0.02-0.20 | 0.5-160 | 65 | 80-90 | 15-20 | 0.3-0.5 | Good | X | >5 |
| EVA | FFE | 0.02-0.20 | 0.5-160 | 85 | 110-120 | 15-20 | 0.3-0.5 | Good | X | >5 |
